ETAV255/SF-6/8EG

The ETAV-02 Air Vent (Snap Fit) is an innovative product that enhances the distribution of air within electronics enclosures, HVAC units and industrial cabinets. As a fully assembled snap-in fan filter unit, it eliminates the hazards of heat, dust and airflow obstruction while significantly improving the cooling capacity of the structure.

Size 255 mm x 255 mm (snap fit)
Dust fabric filter 180 gsm, 10-15mm thick
25-30 Micron, fabric filter
Gasket EPDM Gasketing
Nut & screw Mild steel (zinc Plated)
Suitable for cooling fan 4"Sq. 120mm x 120mm x 38mm
6"Oval. 172mm × 150mm x 51mm
6 Sq. 120mm x 120mm x 38mm
Density Approximately 1.20 g/cm2
Approvals

Colour shade material
